16ft Shipping Container with Single Roll-Up Door

The 16ft shipping container with a single roll-up door provides a balance of storage capacity and accessibility for operations requiring frequent access to stored materials. This container is suited for construction sites, small businesses, and residential applications where space efficiency and ease of entry are priorities.

Key Features

• Single roll-up door providing efficient access without swing clearance requirements

• Corten steel construction with corrosion-resistant properties for outdoor placement

• Marine-grade plywood flooring over steel cross-members

• Locking system compatible with padlocks or security seals

• Compact 16ft footprint suitable for locations with limited space

• Corner castings for lifting and positioning with standard handling equipment

• Forklift pockets for ease of handling and relocation

Detailed Description

The 16ft shipping container with a single roll-up door is constructed from Corten steel, a weathering steel formulation that develops a protective oxide layer when exposed to atmospheric conditions. This material provides structural integrity and resistance to corrosion, making the container suitable for extended outdoor placement across various climate conditions .

The roll-up door mechanism consists of interlocking steel slats that track along guides and coil into a housing above the door opening when raised. This design eliminates the need for swing clearance required by standard cargo doors, making the container suitable for locations where space is restricted . The door is constructed from galvanized steel with weather seals to maintain the container’s weather resistance when closed .

The floor system utilizes marine-grade plywood panels secured to steel cross-members, providing load-bearing capacity suitable for tools, equipment, and palletized goods. The container includes corner castings for lifting and stacking compatibility with standard handling equipment. Forklift pockets are positioned along the container base, allowing repositioning with standard forklift equipment.

Technical Specifications

• External Length: 16 ft (4.88 m)

• External Width: 8 ft (2.44 m)

• External Height: 8 ft 6 in (2.59 m)

• Internal Length: 15 ft 3 in (4.65 m)

• Internal Width: 7 ft 8 in (2.34 m)

• Internal Height: 7 ft 10 in (2.38 m)

• Door Type: Roll-up, single

• Door Construction: Galvanized steel with weather seals

• Door Opening Width: 7 ft (2.13 m) approx.

• Door Opening Height: 6 ft 8 in (2.03 m) approx.

• Floor Material: Marine-grade plywood

• Frame Material: Corten steel

• Locking System: Lock hasps with padlock compatibility

• Approx. Interior Volume: 870 ft³ (24.6 m³)

• Forklift Pockets: Included, 4 positions

• Corner Castings: Standard, 8 positions

Intended Use

This container is suited for the following applications:

• Tool and equipment storage at construction sites

• Small business inventory and supply storage

• Residential storage for seasonal items and equipment

• Material storage for landscaping and maintenance operations

• Mobile storage for events and temporary operations

The 16ft length provides a middle ground between compact 10ft and 20ft units, offering sufficient storage capacity for most small to medium-scale operations while maintaining maneuverability and a smaller footprint .

Package Includes

• 16ft shipping container with single roll-up door

• Marine-grade plywood floor

• Corner castings (8 total)

• Lock hasps on roll-up door

• Forklift pockets (4 positions)

• CSC certification plate
